Line "TS15B"
Process Seal
Not sure which material to choose?
Ask our AI assistant or call our sales team.
Materials
0 / 5 selectedSelect one material for each component.
Dimensions
| A | D | E | L | Size |
|---|---|---|---|---|
| 1 | 1.875 | 1.654 | 2.478 | 16 |
| 1.125 | 1.937 | 1.817 | 2.587 | 18 |
| 1.250 | 2.250 | 2.067 | 2.821 | 20 |
| 1.375 | 2.437 | 2.304 | 3.024 | 22 |
| 1.500 | 2.562 | 2.430 | 3.024 | 24 |
| 1.625 | 2.625 | 2.500 | 3.196 | 26 |
| 1.750 | 2.875 | 2.746 | 3.478 | 28 |
| 1.875 | 3 | 2.871 | 3.478 | 30 |
| 2 | 3.125 | 2.984 | 3.557 | 32 |
| 2.125 | 3.375 | 3.172 | 3.557 | 34 |
| 2.250 | 3.437 | 3.295 | 3.838 | 36 |
| 2.375 | 3.688 | 3.543 | 3.920 | 38 |
| 2.500 | 3.781 | 3.661 | 4.002 | 40 |
| 2.625 | 4 | 3.858 | 4.158 | 42 |
| 2.750 | 4.250 | 4.095 | 4.283 | 44 |
| 2.875 | 4.250 | 4.095 | 4.283 | 46 |
| 3 | 4.375 | 4.252 | 4.377 | 48 |
| 3.125 | 4.500 | 4.350 | 4.377 | 50 |
| 3.250 | 4.625 | 4.448 | 4.440 | 52 |
| 3.375 | 4.781 | 4.646 | 4.502 | 54 |
| 3.500 | 5 | 4.882 | 4.221 | 56 |
| 3.625 | 5.187 | 5.031 | 4.221 | 58 |
| 3.750 | 5.375 | 5.197 | 4.846 | 60 |
| 3.875 | 5.500 | 5.332 | 4.846 | 62 |
| 4 | 5.688 | 5.551 | 4.940 | 64 |
Operating limits
Minimum temperature
-57
°C
78%
-73 °C
0 °C
Maximum temperature
316
°C
74%
0 °C
426 °C
Maximum pressure
1,000
PSI
100%
0 PSI
1,000 PSI
Maximum speed
3,600
RPM
36%
0 RPM
10,000 RPM
