TS181
Zoom

Line "TS18"

Process Seal

Not sure which material to choose?

Ask our AI assistant or call our sales team.

Ask the AI assistant Call sales

Materials

0 / 5 selected

Select one material for each component.

Download data sheet

Dimensions

A E L Size
1 1.626 0.531 16
1.125 1.751 0.531 18
1.250 1.876 0.531 20
1.375 2.063 0.563 22
1.500 2.188 0.563 24
1.625 2.313 0.563 26
1.750 2.501 0.593 28
1.875 2.626 0.593 30
2 2.751 0.593 32
2.125 2.938 0.750 34
2.250 3.064 0.750 36
2.375 3.189 0.750 38
2.500 3.377 0.813 40

Operating limits

Minimum temperature

-57 °C
78%
-73 °C 0 °C

Maximum temperature

204 °C
48%
0 °C 426 °C

Maximum pressure

200 PSI
20%
0 PSI 1,000 PSI

Maximum speed

10,000 RPM
100%
0 RPM 10,000 RPM
