Line "TS50A"
Process Seal
Not sure which material to choose?
Ask our AI assistant or call our sales team.
Materials
0 / 5 selectedSelect one material for each component.
Dimensions
| A | B | E | L | M | N | Size |
|---|---|---|---|---|---|---|
| 1.125 | 2.340 | 1.875 | 1 | 0.625 | 1 | 18 |
| 1.625 | 2.832 | 2.437 | 1.125 | 0.625 | 1 | 26 |
| 2.125 | 3.330 | 3.125 | 1.153 | 0.625 | 1 | 34 |
Operating limits
Minimum temperature
-57
°C
78%
-73 °C
0 °C
Maximum temperature
316
°C
74%
0 °C
426 °C
Maximum pressure
175
PSI
18%
0 PSI
1,000 PSI
Maximum speed
3,600
RPM
36%
0 RPM
10,000 RPM
