TSM7N
Zoom

Line "TSM7N"

Process Seal

Not sure which material to choose?

Ask our AI assistant or call our sales team.

Ask the AI assistant Call sales

Materials

0 / 5 selected

Select one material for each component.

Download data sheet

Dimensions

A B C E L M N
14 25 21 25 25 5.500 10
16 27 23 27 25 5.500 10
18 33 27 33 26 7 11.500
20 35 29 35 26 7 11.500
22 37 31 37 26 7 11.500
24 39 33 39 28.500 7 11.500
25 40 34 40 28.500 7 11.500
28 43 37 43 31 7 11.500
30 45 39 45 31 7 11.500
32 48 42 47 31 7 11.500
33 48 42 48 31 7 11.500
35 50 44 50 31 7 11.500
38 56 49 55 31 8 14
40 58 51 57 31 8 14
43 61 54 60 31 8 14
45 63 56 62 31 8 14
48 66 59 65 31 8 14
50 70 62 67 32.500 8.500 15
53 73 65 70 32.500 8.500 15
55 75 67 72 32.500 8.500 15
58 78 70 79 37.500 8.500 15
60 80 72 81 37.500 8.500 15
63 83 75 84 37.500 8.500 15
65 85 77 86 37.500 9.500 15
68 90 81 89 34.500 9.500 18
70 92 83 91 42 9.500 18
75 97 88 99 42 9.500 18
80 105 95 104 41.800 10 18.200
85 110 100 109 41.800 10 18.200
90 115 105 114 46.800 10 18.200
95 120 110 119 47.800 10 17.200
100 125 115 124 47.800 10 17.200

Operating limits

Minimum temperature

-57 °C
78%
-73 °C 0 °C

Maximum temperature

204 °C
48%
0 °C 426 °C

Maximum pressure

230 PSI
23%
0 PSI 1,000 PSI

Maximum speed

3,600 RPM
36%
0 RPM 10,000 RPM
