Line "TS165"
Cartridge
Not sure which material to choose?
Ask our AI assistant or call our sales team.
Materials
0 / 5 selectedSelect one material for each component.
Dimensions
| A | B | C | D | E | F | G | H | Size |
|---|---|---|---|---|---|---|---|---|
| 1.125 | 5.500 | 1.960 | 1.890 | 1.950 | 0.843 | 2.880 | 0.437 | 18 |
| 1.375 | 4.360 | 2.275 | 2.205 | 1.950 | 0.840 | 3.400 | 0.562 | 22 |
| 1.750 | 5.500 | 2.668 | 2.598 | 1.950 | 0.863 | 3.750 | 0.562 | 28 |
| 1.875 | 5.500 | 2.826 | 2.756 | 1.950 | 0.903 | 3.880 | 0.562 | 30 |
| 2.125 | 6 | 3.141 | 3.071 | 1.950 | 0.903 | 4.250 | 0.562 | 34 |
| 2.625 | 6.500 | 3.691 | 3.622 | 1.950 | 1.021 | 5 | 0.562 | 42 |
Operating limits
Minimum temperature
-57
°C
78%
-73 °C
0 °C
Maximum temperature
316
°C
74%
0 °C
426 °C
Maximum pressure
450
PSI
45%
0 PSI
1,000 PSI
Maximum speed
3,600
RPM
36%
0 RPM
10,000 RPM
