Line "TS57"
Cartridge
Not sure which material to choose?
Ask our AI assistant or call our sales team.
Materials
0 / 5 selectedSelect one material for each component.
Dimensions
| A | B | C | D | E | F | G | H | I | Size |
|---|---|---|---|---|---|---|---|---|---|
| 1.375 | 4 | 2.125 | 2.062 | 1.750 | 1.187 | 3.250 | 0.437 | 2.625 | 22 |
| 1.875 | 5.625 | 2.625 | 2.562 | 1.750 | 1.312 | 3.750 | 0.437 | 3.125 | 30 |
| 2.625 | 7.375 | 3.625 | 3.562 | 1.750 | 1.593 | 5.500 | 0.562 | 4.250 | 42 |
Operating limits
Minimum temperature
-57
°C
78%
-73 °C
0 °C
Maximum temperature
204
°C
48%
0 °C
426 °C
Maximum pressure
150
PSI
15%
0 PSI
1,000 PSI
Maximum speed
3,600
RPM
36%
0 RPM
10,000 RPM
