Line "TSC"
Single Spring Seal
Not sure which material to choose?
Ask our AI assistant or call our sales team.
Materials
0 / 5 selectedSelect one material for each component.
Dimensions
| A | B | D | E | L | M | E1 | L1 | L2 | Size |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 1.130 | 0.188 | 0.345 | 0.312 | 1.320 | 0.250 | 1/2 | ||
| 1.187 | 1.440 | 0.265 | 0.345 | 0.344 | 1.625 | 0.282 | 5/8 | ||
| 1.250 | 1.440 | 0.265 | 0.345 | 0.406 | 1.625 | 0.344 | 5/8 | ||
| 1.375 | 1.575 | 0.235 | 0.375 | 0.406 | 1.719 | 0.344 | 3/4 | ||
| 1.375 | 1.575 | 0.235 | 0.375 | 0.200 | 1.719 | 0.167 | 3/4 | ||
| 1.375 | 0.235 | 1.771 | 0.200 | 1.719 | 0.452 | 0.167 | 3/4 | ||
| 1.625 | 1.850 | 0.312 | 0.393 | 0.437 | 2.008 | 0.375 | 1 | ||
| 1.889 | 2.047 | 0.314 | 0.432 | 0.314 | 2.244 | 0.252 | 1-1/8 |
Operating limits
Minimum temperature
-57
°C
78%
-73 °C
0 °C
Maximum temperature
204
°C
48%
0 °C
426 °C
Maximum pressure
100
PSI
10%
0 PSI
1,000 PSI
Maximum speed
5,000
RPM
50%
0 RPM
10,000 RPM
